| Details |
|
| Product code |
CCR2116-12G-4S+ |
| Architecture |
ARM 64bit |
| CPU |
AL73400 |
| CPU core count |
16 |
| CPU nominal frequency |
2000 MHz |
| Switch chip model |
98DX3255 |
| Dimensions |
443 x 199 x 44 mm |
| RouterOS license |
6 |
| Operating System |
RouterOS v7 |
| Size of RAM |
16 GB |
| Storage size |
128 MB |
| Storage type |
NAND |
| MTBF |
Approximately 200‘000 hours at 25C |
| Tested ambient temperature |
-20°C to 60°C |
| IPsec hardware acceleration |
Yes |
| Suggested price |
$995.00 |
Powering
| Details |
|
| Number of AC inputs |
2 |
| AC input range |
100-240 |
| Max power consumption |
83 W |
| Max power consumption without attachments |
60 W |
| Cooling type |
4 fans |
Ethernet
| Details |
|
| 10/100/1000 Ethernet ports |
13 |
Fiber
| Details |
|
| SFP+ ports |
4 |
Peripherals
| Details |
|
| Serial console port |
RJ45 |
| Number of M.2 slots |
1 |
Other
| Details |
|
| CPU temperature monitor |
Yes |
| PCB temperature monitor |
Yes |
| Mode button |
Yes |
Certification & Approvals
| Details |
|
| Certification |
CE, EAC, ROHS |
Included parts
IEC cord
Rackmount bracket white
K-57 kit
